MPN: SV227-SF2SNM
BRAND: Sinclair Technologies
PRODUCT TYPE: Base Antenna
SKU: 10114

Sinclair Technologies SV227-SF2SNM

148-174 MHz 7dB Corner Reflector Antenna

$2,299⁹⁵

Shipping calculated at checkout.

DOCUMENTS

Specs

285839 SV227 SF2SNM+SPEC+SHEET

Description

Manufacturer

Sinclair

Model #

SV227-SF2SNM

Product Description

148-174 7dB Corner Reflector Antenna

Product Narrative

SINCLAIR's 148 – 174 MHz corner reflector. 7dB gain, 250 W. Includes harness with N Male termination and mounting hardware.

Specific Freq. (MHz)

148-174 MHz

Gain (dB)

7dB

Maximum Input Power (Watts)

250

Maximum VSWR

1.5:1

Vert. Beamwidth (-3dB)

75 Deg.

Lightning Protection

DC Ground

Direct Termination

Includes harness with N male termination

Overall Length

49''

Rated Wind Velocity (MPH)

100

Mount Hardware

Clamp Set

Weight

35 Lbs.

Warranty

6 Years
