Product Description
824-960 MHz 6 dBi Log Periodic Yagi Antenna
Product Narrative
L-COM's HG906YE-NF hypergain HG906YE high performance Yagi antenna in an economical package combines accurate gain with a wide beam-width, ideally suited for directional applications in the 900 MHz ISM and GSM bands. This series of Yagi antennas provides the user with anodized aluminum boom, solid elements, low loss series 400 coax, and rugged mounting hardware.
Manufacturer
L-Com Connectivity Product
Maximum Rated Wind Velocity
150 mile/h
RF Connectors
N Female
Gain dBi
6 dBi
Maximum Power
100 W
Maximum VSWR
1.5:1
Connector Placement
Bottom
Item Width
2.5 in
Item Height
8.4 in
Polarization
Horizontal, Vertical
Specific Frequency
824-960 MHz
Item Weight
1.56 lb
Item Length
14.2 in
