Manufacturer
DuraComm
Product Description
1000 Watt 2U Rack Mount Isolated DC to DC Converter
Product Narrative
The DCDC-130-48 is a 2U rack mount DC-to-DC converter that is capable of 1000 watts of power. It has isolated inputs and output with 2000 VAC isolation, so it can be used in positive ground installations. All DCDC-130 models come with a standard voltage and amperage selectable meter. Along with thermostat controlled forced air-cooling. All DCDC-130 models come equipped with short circuit, overload, and over temperature protection.
Output Current (Amps):
20
Output Voltage VDC:
48
RC & DC-OK:
NO
Input Range VDC:
72-144
Output Range VDC:
46-60
Weight (lbs):
12
