Manufacturer
CommScope
Model #
FFV4-65A-R3-V1
Description
COMMSCOPE 12-port sector antenna, 4x 617-894 and 8x 1695–2690 MHz, 65° HPBW, 3x RET
Item Weight
79.366 lb
Electrical Downtilt
Variable
Polarization
+/- 45 Degrees
Horizontal Beamwidth
67 deg, 65 deg, 63 deg, 62 deg, 61 deg, 60 deg, 59 deg, 58 deg
RF Connectors
4.3-10 Female
Maximum Rated Wind Velocity
149.75 mile/h
Maximum Power
900 W
Connector Placement
Bottom
Item Width
25.12 in
Item Height
9.25 in
Item Length
48.19 in
Specific Frequency
2300 - 2500 MHz, 1920 - 2200 MHz, 1850 - 1990 MHz, 1695 - 1880 MHz, 806 - 894 MHz, 698 - 806 MHz, 617 - 698 MHz
Gain dBi
18.1 dBi, 17.6 dBi, 16.9 dBi, 16.4 dBi, 13.1 dBi, 13.0 dBi, 12.6 dBi
