Description
Description
Manufacturer
Sinclair Technologies
Mfg. Model No.
I2113A
Product Description
SINCLAIR's I2113A 132 – 174 MHz compact rugged isolator and circulator, 60 W load. This isolator and circulator has low insertion loss, high isolation, and is temperature-compensated. Each unity is optimized to customer specific frequency. *Factory tuned to
Temperature Range
-30-60 deg C
Minimum Isolation
35 dB
Bandwidth
5 MHz
Item Width
2.5 in
Maximum VSWR
1.25:1
Item Height
2.5 in
Item Length
1.4 in
RF Connectors
N Female
Maximum Power Input
125 W
Frequency Range
132-174 MHz
