Times Microwave LMR-400FR
Regular price
$329
Unit price
Shipping calculated at checkout.
DOCUMENTS
DOCUMENTS
Specs
Description
Description
Manufacturer
Times Microwave
Model #
LMR®-400FR
Product Description
50 Ohm Coaxial Cable - Low Loss Fire Retardant RG8/U Cable
Cable Type
3/8" Braided
Connectors
N/A
Shield %
100% foil 88% braided
Impedance
50 Ohms
VOP.
85%
Center Conductor
0.108" Solid
Insulation
Polyethylene foam FRPE Jacket
Other Spec
MSHA Approved
Nom. core O.D. (in.)
0.285"
Nom. O.D. (in.)
0.405"
Losses Shown are based on 100 Foot Length
loss 50 MHz
0.90 db
loss 100 MHz
1.4 db
loss 400 MHz
2.7 db
loss 900 MHz
3.9 db
loss 1000 MHz
4.11 db
Nom. Capacitance (pF/ft)
23.9
Sold By
Per Foot (Note - When ordering) 1 unit sold = 1 foot, 10 units sold = 10 feet, 50 units sold = 50 feet, etc.
Warranty
5 Years
