Description
The Andrew 1132DZ is a brass splice connector designed to join two sections of HELIAX EW132 elliptical microwave waveguide.
Operating from 14.0 to 15.35 GHz, it provides a direct waveguide-to-waveguide connection without requiring rectangular waveguide flanges or a separate adapter.
The splice supports both tab-flare and tool-flare attachment methods and is designed for pressurized microwave waveguide systems.
Its brass construction provides mechanical durability, while its low typical insertion loss of 0.01 dB helps maintain microwave transmission performance.
Technical Specifications
|
Specification |
Description |
|---|---|
|
Manufacturer |
Andrew / Amphenol |
|
Former Brand |
CommScope |
|
Part Number |
1132DZ |
|
Product Series |
HELIAX |
|
Product Type |
Elliptical Waveguide Splice Connector |
|
Compatible Waveguide |
EW132 family |
|
Operating Frequency |
14.0–15.35 GHz |
|
Connector Interface |
Direct Splice |
|
Body Style |
Straight Splice |
|
Body Material |
Brass |
|
Attachment Method |
Tab-Flare / Tool-Flare |
|
Pressurizable |
Yes |
|
Typical Insertion Loss |
0.01 dB |
|
Overall Length |
2.71" (68.834 mm) |
|
Width |
2.10" (53.34 mm) |
|
Inner Contact Plating |
Unplated |
|
Outer Contact Plating |
Unplated |
|
Operating Temperature |
−55°C to +85°C |
|
Storage Temperature |
−55°C to +85°C |
|
Manufacturer Net Weight |
1.543 lb (0.70 kg) |
|
RoHS Compliance |
Compliant |
