Manufacturer
Astron
Model #
VRM-50M-BB
Product Description
50 Amp Variable Amp/Voltage Power Supply w/Battery Back Up
Input Voltage (VAC)
115 Volts AC
Output Voltage (VDC)
2 to 15 Volts DC (Selectable)
Amperage (Cont.)
37
Amperage (Intermittent)
50
Description
Solid State electronically regulated. Feature fold-back current limiting to protect the power supply from excessive current or shorted output. Chassis mounted fuse. Less than 5 mv ripple peak to peak (full load and low line).
Features include:
* Precision regulation adjustable from 2 to 15 Volts DC
* Adjustable Amperage current 1.5 to 35 amps
* Separate lighted voltage and current meters
* Short circuit and over-voltage protection
* Low peak to peak ripple of less than 5 mv
* High surge capacity
* Fold-back current limiting
* Grounded power cord
* External fuse access
Ripple Voltage
5 mV
Fold-Back Protection
Yes
Crowbar Protection
Yes
Dimensions
19 x 5.25 x 12.5 in
Product Narrative
Astron linear power supplies are heavy duty and solid state electronically regulated.
Warranty
1 yr
