Empower your team with a faster way to communicate. The RMV2080 on-site two-way business radio helps you communicate instantly, without missing a beat. With crisp, clear audio throughout the workplace and exceptional durability, the RMV2080 won’t quit in high noise, harsh conditions, and high use.
The RMV2080 2 watt radio operates on 27 VHF business exclusive frequencies and is FCC Narrowband ready. Enhanced audio quality, a rugged design, and versatile HTML-based customer programming software, make this radio an exceptional choice for all of your on-site business needs. Advanced features such as customized channel announcement keep your hands free, so you can focus on the task at hand. NOAA Weather Alerts automatically notify you of official weather warnings, watches and forecasts so you can prepare your workforce.
Whether you’re coordinating resources at the construction site or on the manufacturing line, the RMV2080 two-way radio is tested to last. Unleash the power of your RM series radio with accessories that are comfortable, durable and discreet to fit the way you work.
What's in the box
- Standard Package
- RM Radio
- Standard li-ion battery
- Drop-in charger
- Charging power supply
- Swivel holster
- Operating Manual
- Safety Manual
General Specifications
Frequency Range
VHF (150.8 to 160)
Channel Capacity
8 Channels
Channel Bandwidth
12.5kHz
Dimensions with:
4.5 in H x 2.2 in W x 1.6 in D (115.6 mm H x 57.6 mm W x 40.5 mm D)
Standard Li-Ion Battery
4.5 in H x 2.2 in W x 1.6 in D (115.6 mm H x 57.6 mm W x 40.5 mm D)
High Capacity Li-Ion Battery
8.9 oz (252g)
Weight with:
9.0 oz (255g)
Standard Li-Ion Battery
Up to 15 hours with battery save on or up to 12 hours without battery save.
High Capacity Li-Ion Battery
Available in Q4/2013
Average Battery Life @ 5/5/90: with Standard 2150 mAH Li-Ion Battery
3.7V Li-Ion
with High Capacity 3200 mAH Li-Ion Battery
RECEIVER
70 dB @ 12.5 kHz 75 dB @ 25 kHz
Sensitivity (12 dB SINAD)
70 dB
Adjacent Channel Selectivity
90 dB
Intermodulation Rejection
< 5%
Spurious Response Rejection (blocking 1 MHz)
-50 dB
CSQ Hum and Noise @ 12.5 kHz
-45 dB
PL Hum and Noise @ 12.5 kHz
< -54 dBm
DPL Hum and Noise @ 12.5 kHz
< -52 dBm
Spurious Emissions (< 1 GHz)
1.5W @ 8 ohms
Spurious Emissions (> 1 GHz)
Audio Output @ < 5% Distortion
RF Output: High (conducted) Low (conducted)
< 1.5 ppm
Frequency Stability
< -45 dBc
Spurs and Harmonics
-36 dbm for f < 1GHz, -30 dbm for f> 1GHz
FM Hum and Noise
±2.5 kHz @ 12.5 kHz ±5.0 kHz @ 25.0 kHz
Modulation Limiting
70 dBc
Adjacent Channel Power
-36 dbm for f < 1GHz, -30 dbm for f> 1GHz
Spurious Emissions @ 12.5 kHz
-36 dbm for f < 1GHz, -30 dbm for f> 1GHz
Spurious Emissions @ 25 kHz
+1 to -3 dB
Audio Frequency Response (0.3 - 3.0 kHz)
< 2%
MILITARY SPECIFICATIONS
MIL 810 F Methods/ Procedures
Standard
500.4 / Procedure 1
Low Pressure
501.4 / Procedure 1,2
High Temperature
501.4 / Procedure 1,2
Low Temperature
503.4 / Procedure 1
Temperature Shock
505.4 / Procedure 1
Solar Radiation
506.4 / Procedure 1
Humidity
510.4 / Procedure 1
Vibration
516.5 / Procedure 1
ENVIRONMENTAL SPECIFICATIONS
-30ºC to +60ºC (Radio)
Operating Temperature
IP55
Sealing
Polycarbonate Housing passes EIA 603*
Shock and Vibration
Satisfied EIA 603*
Warranty
2-Year Limited Radio Warranty
